When Your Hash Becomes a String: Hunting Ruby’s Million-to-One Memory Bug

Every developer who maintains Ruby gems knows that sinking feeling when a user reports an error that shouldn't be possible. Not "difficult to reproduce", but truly impossible according to everything you know about how your code works.

That's exactly what hit me when Karafka user's error tracker logged 2,700 identical errors in a single incident:

NoMethodError: undefined method 'default' for an instance of String
vendor/bundle/ruby/3.4.0/gems/karafka-rdkafka-0.22.2-x86_64-linux-musl/lib/rdkafka/consumer/topic_partition_list.rb:112 FFI::Struct#[]

The error was because something was calling #default on a String. I had never used a #default method anywhere in Karafka or rdkafka-ruby. Suddenly, there were 2,700 reports in rapid succession until the process restarted and everything went back to normal.

The user added casually: "No worry, no harm done since this hasn't occurred on prod yet."

Yet. That word stuck with me.

Something had to change. Fast.

TL;DR: FFI < 1.17.0 has missing write barriers that cause Ruby's GC to free internal Hashes, allowing them to be replaced by other objects at the same memory address. Rare but catastrophic.

The Impossible Error

I opened the rdkafka-ruby code at line 112:

native_tpl[:cnt].times do |i|
  ptr = native_tpl[:elems] + (i * Rdkafka::Bindings::TopicPartition.size)
  elem = Rdkafka::Bindings::TopicPartition.new(ptr)

  # Line 112 - Where everything exploded
  if elem[:partition] == -1

The crash happened when accessing elem[:partition]. But elem is an FFI::Struct - a foreign function interface structure that bridges Ruby and C code and partition was declared as an integer:

class TopicPartition < FFI::Struct
  layout :topic, :string,
         :partition, :int32,
         :offset, :int64,
         :metadata, :pointer,
         :metadata_size, :size_t,
         :opaque, :pointer,
         :err, :int,
         :_private, :pointer
end

I dove into FFI's internals to understand what was happening. FFI doesn't use many Hashes, neither in Ruby nor in its C extension - there are only a few critical data structures. The most important one is rbFieldMap, an internal Hash that every struct layout maintains to store field definitions. When you access elem[:partition], FFI looks up :partition in this Hash to find the field's type, offset, and size.

This Hash is the heart of the FFI's struct system. Without it, FFI can't map field names to their C memory locations.

Why would it be calling default on a String?

I searched the entire codebase. No calls to #default anywhere in my code. I checked FFI's Ruby code. No calls to #default there either.

But #default is a Hash method. Ruby's Hash implementation calls hash#default when you access a key that might not exist.

I stared at the backtrace. After billions of messages processed successfully, something in FFI's internals had fundamentally broken. An internal Hash that should contain field definitions was somehow... a String.

Chasing Shadows: The musl Hypothesis

The gem was precompiled: karafka-rdkafka-0.22.2-x86_64-linux-musl. That suffix made me immediately suspicious. The user was running ruby:3.4.5-alpine in Docker, which uses musl libc instead of glibc.

I've debugged enough production issues to know that precompiled gems and Alpine Linux make a notorious combination. Different libc versions, different struct alignment assumptions, different CPU architecture quirks.

"This has to be musl," I thought. I spent some time building diagnostic scripts:

require 'ffi'

# Check FFI integer type sizes
module Test
  extend FFI::Library

  class IntTest < FFI::Struct
    layout :a, :int
  end

  class Int32Test < FFI::Struct
    layout :a, :int32
  end
end

int_size = Test::IntTest.size
int32_size = Test::Int32Test.size

puts "FFI :int size: #{int_size} bytes"
puts "FFI :int32 size: #{int32_size} bytes"
puts "Match: #{int_size == int32_size ? 'Yes' : 'No'}"

The response came back:

FFI :int size: 4 bytes
FFI :int32 size: 4 bytes
Match: Yes

The sizes matched. That ruled out basic type mismatches. But maybe alignment?

I sent another diagnostic to check struct padding:

# Check actual struct field offsets
module AlignTest
  extend FFI::Library

  class WithInt < FFI::Struct
    layout :topic, :pointer, :partition, :int32, :offset, :int64,
           :metadata, :pointer, :metadata_size, :size_t, :opaque, :pointer,
           :err, :int, :_private, :pointer
  end

  class WithInt32 < FFI::Struct
    layout :topic, :pointer, :partition, :int32, :offset, :int64,
           :metadata, :pointer, :metadata_size, :size_t, :opaque, :pointer,
           :err, :int32, :_private, :pointer
  end
end

err_offset_int = AlignTest::WithInt.offset_of(:err)
err_offset_int32 = AlignTest::WithInt32.offset_of(:err)
puts "Struct alignment: :err offset #{err_offset_int} vs #{err_offset_int32}"

Response:

Struct alignment: :err offset 48 vs 48

Perfect alignment. Now let's check the actual compiled struct from the gem:

actual_size = Rdkafka::Bindings::TopicPartition.size
actual_err_offset = Rdkafka::Bindings::TopicPartition.offset_of(:err)
puts "Actual gem struct: size=#{actual_size}, err_offset=#{actual_err_offset}"

expected_size = 64
expected_err_offset = 48
puts "Expected: size=#{expected_size}, err_offset=#{expected_err_offset}"

Response:

Actual gem struct: size=64, err_offset=48
Expected: size=64, err_offset=48

Everything matched.

Every "obvious" explanation had failed. The struct definitions were perfect. The memory layout was correct. There was no ABI mismatch, no musl-specific quirk, no CPU architecture issue.

And yet the undefined method 'default' for an instance of Stringoccurred.

The Moment Everything Stopped Making Sense

I went back to that error message with fresh eyes. Why default specifically?

In Ruby, when you access a Hash with hash[key], the implementation can call hash.default to check for a default value if the key doesn't exist. So if FFI is trying to call #default on a String, this would mean thatrbFieldMap - the internal Hash that stores field definitions - is actually a String.

Sounds crazy, but wait! What if there was a case where Ruby could replace a Hash with a String at runtime? Not corrupt the Hash's data, but literally free the Hash and allocate a String in the same memory location?

That would explain everything. The C code would still have a pointer to memory address 0x000078358a3dfd28, thinking it points to a Hash. But Ruby's GC would have freed that Hash, and the memory allocator could create a String at the exact same address. The pointer would be valid. The memory would contain valid data. Just... the wrong type of data.

• Not corrupted.
• Not misaligned.
• Not reading wrong offsets.

An object changing type at runtime. That shouldn't be possible unless... I searched FFI's GitHub issues and found #1079: "Crash with [BUG] try to mark T_NONE object" - about segfaults, not this specific error. But buried in the comments, KJ mentioned "missing write barriers" in FFI's C extension.

A write barrier is a mechanism that tells Ruby's garbage collector about references between objects. When C code stores a Ruby object pointer without using RB_OBJ_WRITE, the GC doesn't know that reference exists. The GC can then free the object, thinking nothing needs it anymore.

That's when it clicked. If FFI's rbFieldMap Hash was being freed by the GC, then Ruby could allocate a String in that exact memory location.

But first, I needed to understand the #1079 issue better. I wrote a simple reproduction:

require 'ffi'

puts "Ruby: #{RUBY_VERSION} | FFI: #{FFI::VERSION}"

# Enable aggressive GC to trigger the bug faster
GC.stress = 0x01 | 0x04

i = 0

loop do
  i += 1

  # Create transient struct class that immediately goes out of scope
  struct_class = Class.new(FFI::Struct) do
    layout :field1, :int32,
           :field2, :int64,
           :field3, :pointer,
           :field4, :string,
           :field5, :double,
           :field6, :uint8,
           :field7, :uint32,
           :field8, :pointer
  end

  instance = struct_class.new
  instance[:field1] = rand
  instance[:field2]
  # ... access various fields

  field = struct_class.layout[:field5]
  field.offset
  field.size

  print "." if i % 1000 == 0
end

This reproduced the #1079 segfaults beautifully - the "T_NONE object" errors where the GC frees objects so aggressively that Ruby tries to access null pointers.

rb_obj_info_dump:
/3.4.0/gems/ffi-1.16.3/lib/ffi/struct_layout_builder.rb:171: [BUG] try to mark T_NONE object
ruby 3.4.7 (2025-10-08 revision 7a5688e2a2) +PRISM [x86_64-linux]

-- Control frame information -----------------------------------------------
c:0044 p:---- s:0246 e:000245 CFUNC  :initialize
c:0043 p:---- s:0243 e:000242 CFUNC  :new
c:0042 p:0033 s:0236 e:000235 METHOD /gems/3.4.0/gems/ffi-1.16.3/lib/ffi/struct_layout_builder.rb:171

But my production bug wasn't a segfault. It was a magical transformation. The timing had to be different.

With GC.stress = true, the GC runs after every possible allocation. That causes immediate segfaults because objects get freed before Ruby can even allocate new objects in their memory slots.

But for a Hash to become a String, you need:

1. GC to run and free the Hash
2. Time to pass between the free and the next access
3. Ruby to allocate a String in that exact memory slot
4. Code to try accessing the "Hash" that's now a String

I couldn't use GC.stress. I needed natural GC timing with precise memory pressure.

Down the Rabbit Hole

I dove deeper into FFI's C extension code. In ext/ffi_c/StructLayout.c, I found the vulnerable code:

static VALUE
struct_layout_initialize(VALUE self, VALUE fields, VALUE size, VALUE align)
{
    StructLayout* layout;
    // ... initialization code ...

    layout->rbFieldMap = rb_hash_new();  // ← NO WRITE BARRIER
    layout->rbFields = rb_ary_new();
    layout->rbFieldNames = rb_ary_new();

    // Without RB_OBJ_WRITE, the GC doesn't know about these references!
    // ...
}

When FFI creates a struct layout, it allocates three Ruby objects:

• a Hash for field lookups,
• an Array of fields,
• and an Array of field names.

It stores pointers to these objects in a C struct.

But it didn't use RB_OBJ_WRITE to register these references with Ruby garbage collector in FFI 1.16.3.

From the GC's perspective, the following is happening:

1. A Hash is allocated at memory address 0x000078358a3dfd28.
2. No Ruby code stores a reference to ths memory address (as far as the GC can see).
3. The struct class goes out of scope.
4. The GC thinks: "Nobody needs this Hash anymore".
5. The GC frees the memory.
6. Ruby allocates a String at the address 0x000078358a3dfd28.
7. FFI's C code still has the pointer, thinking it points to a Hash.
8. Boom: undefined method 'default' for String.

The fix in FFI 1.17.0 added proper write barriers:

static VALUE
struct_layout_initialize(VALUE self, VALUE fields, VALUE size, VALUE align)
{
    StructLayout* layout;
    // ... initialization code ...

    RB_OBJ_WRITE(self, &layout->rbFieldMap, rb_hash_new());  // ← FIXED!
    RB_OBJ_WRITE(self, &layout->rbFields, rb_ary_new());
    RB_OBJ_WRITE(self, &layout->rbFieldNames, rb_ary_new());

    // Now the GC knows: "self owns these objects, don't free them"
    // ...
}

This single macro call, RB_OBJ_WRITE, tells Ruby's garbage collector: "This C struct holds a reference to this Ruby object. Don't free it while the struct is alive."

Without it, you have a use-after-free vulnerability where C thinks that it has a valid pointer, but Ruby has freed the memory and reused it for something else entirely.

Building the Perfect Trap

Understanding the bug wasn't enough. I needed to reproduce it. Not the #1079 segfaults - the specific case where a Hash becomes something else.

The requirements were precise:

• Thousands of transient struct class definitions that go out of scope.
• Natural memory pressure to trigger GC (not GC.stress which causes segfaults).
• Time between GC and field access for Ruby to allocate new objects.
• Multi-threaded execution to increase memory churn.
• Constant struct creation to maximize the replacement window.

Here's what I have built:

#!/usr/bin/env ruby

require 'ffi'

# Unbuffer stdout so we see output immediately
$stdout.sync = true
$stderr.sync = true

2.times do
  Thread.new do
    loop do
      # Create an array to hold references temporarily
      # This creates more allocation pressure
      arr = []

      # Allocate many strings rapidly
      5000.times do
        arr << rand.to_s * 100
        arr << Time.now.to_s
        arr << "test string #{rand(10000)}"
      end
    end
  end
end

sleep(0.1)

# Keep all struct instances here so we can access them later
garbage_strings = []

ars = Array.new(5) do |round|
  Thread.new do
    round_instances = []

    10000.times do |i|
      # Create a new struct class - this creates an rbFieldMap
      klass = Class.new(FFI::Struct) do
        layout :partition, :int32,
               :offset, :int64,
               :metadata, :pointer,
               :err, :int32,
               :value, :int64
      end

      # Create instance from this class
      ptr = FFI::MemoryPointer.new(klass.size)
      instance = klass.new(ptr)
      instance[:partition] = round * 100 + i
      instance[:offset] = (round * 100 + i) * 1000
      instance[:err] = 0

      round_instances << instance
    end

    round_instances.each_with_index do |instance, i|
      begin
        partition = instance[:partition]
        offset = instance[:offset]
        err = instance[:err]
      rescue NoMethodError => e
        puts "\n" + "=" * 60
        puts "🐛 BUG REPRODUCED! 🐛"
        puts "=" * 60
        puts "Error: #{e.message}"
        puts "\nBacktrace:"
        puts e.backtrace[0..10]
        exit 1
      end
    end

    # Clear old strings to increase memory churn
    if garbage_strings.size > 50_000
      garbage_strings.shift(25_000)
    end
  end
end

ars.each(&:join)

Key differences from typical FFI tests:

• No GC.stress (it would cause segfaults, not object replacement)
• Multiple threads creating memory pressure simultaneously
• Natural GC timing from memory allocation patterns
• Time gap between struct creation and field access
• Transient classes that go out of scope immediately

I wrapped it in a Docker container with memory constraints:

FROM ruby:3.4.5-alpine

RUN apk add --no-cache build-base

RUN gem install ffi -v 1.16.3

WORKDIR /app
COPY poc.rb .

CMD ["ruby", "poc.rb"]

Then I created a bash script to run it in a loop, filtering for the specific error:

#!/bin/bash

run_count=0
log_dir="./logs"
mkdir -p "$log_dir"

echo "Building Docker image..."
docker build -t ffi-bug-poc .

echo "Running POC in a loop until bug is reproduced..."
echo "Looking for exit code 1 with 'undefined' in output"
echo

while true; do
  run_count=$((run_count + 1))
  timestamp=$(date +%Y%m%d_%H%M%S)
  log_file="${log_dir}/run_${run_count}_${timestamp}.log"

  echo -n "Run #${run_count} at $(date +%H:%M:%S)... "

  # Run with memory constraints to increase GC pressure
  docker run --rm \
    --memory=512m \
    --memory-swap=0m \
    ffi-bug-poc > "$log_file" 2>&1

  exit_code=$?

  # Filter: only care about exit code 1 with "undefined" in output
  # Ignore segfaults (exit 139) - those are from #1079
  if [ $exit_code -eq 1 ] && grep -qi "undefined" "$log_file"; then
    echo ""
    echo "🐛 BUG REPRODUCED on run #${run_count}! 🐛"
    cat "$log_file"
    exit 0
  elif [ $exit_code -eq 0 ]; then
    echo "completed successfully (no bug)"
    rm "$log_file"
  else
    echo "exit code $exit_code (segfault) - continuing..."
  fi

  sleep 0.1
done

I hit Enter and watched the terminal:

Building Docker image...
Running POC in a loop until bug is reproduced...
Looking for exit code 1 with 'undefined' in output

Run #1 at 14:32:15... completed successfully (no bug)
Run #2 at 14:32:18... completed successfully (no bug)
Run #3 at 14:32:21... exit code 139 (segfault) - continuing...
Run #4 at 14:32:24... completed successfully (no bug)

Lots of segfaults - those were the #1079 issue. I was hunting for the specific undefined method error.

After realizing I needed even more memory churn, I opened multiple terminals and ran the loop script several times in parallel. Within minutes:

Run #23 at 15:18:42... exit code 139 (segfault) - continuing...
Run #24 at 15:18:45... completed successfully (no bug)
Run #25 at 15:18:48...

============================================================
🐛 BUG REPRODUCED! 🐛
============================================================
Error: undefined method 'default' for an instance of String

Backtrace:
  poc.rb:82:in `[]'
  poc.rb:82:in `block (2 levels) in <main>'
  poc.rb:80:in `each'
  poc.rb:80:in `each_with_index'
  poc.rb:80:in `block in <main>'
  <internal:numeric>:237:in `times'
  poc.rb:50:in `<main>'
============================================================

There!

Not a segfault. Not the T_NONE error from #1079. There it is, the exact error from production: undefined method 'default' for an instance of String

An FFI internal Hash had been freed by the GC and replaced by a String object in the same memory location!

The Microsecond Window

Here's what happens in those microseconds when the bug triggers:

The Hash didn't get corrupted. It ceased to exist. A String was born in its place, wearing the Hash's memory address like a stolen identity.

What This Means for Ruby's Memory Model

This bug reveals something fundamental about how Ruby manages memory at the lowest level.

Objects don't have permanent identities. They're data structures at the memory addresses. When the garbage collector frees memory, Ruby will reuse it. If you're holding a C pointer to that address without proper write barriers, you're now pointing at whatever Ruby decided to create there next.

• Your Hash can become a String.
• Your Array can become an Integer.
• Your carefully constructed object can transform into something completely different.

No warning. No error. Just different methods that make no sense.

It's like coming home to find a stranger living in your house, wearing your clothes, answering to your name. And when you say "but you're supposed to respond to default," they look at you confused: "I'm a String. I don't have that method."

This is why write barriers exist. They're not optional extras for C extension authors. They're how you tell the garbage collector: "I'm holding a reference. Don't free this. Without them, you have use-after-free bugs that can manifest as objects changing identity at runtime.

The Fix and The Future

If you're using FFI < 1.17.0, the fix is straightforward:

# Gemfile
gem 'ffi', '~> 1.17.0'

That's it. Upgrade and the bug goes from million-to-one to zero.

The fix made by KJ adds proper write barriers throughout FFI's C codebase. The garbage collector now knows not to free rbFieldMap while it's still needed. Your Hashes stay Hashes. Your Strings stay Strings. Reality remains consistent.

But here's why this matters beyond just FFI users.

Why One in a Million?

This bug requires perfect timing:

1. Create transient struct CLASS definitions (not just instances):

   • Normal code: Defines classes once at startup, reuse forever.
   • My stress test: 50,000 transient classes immediately going out of scope.

2. Precise GC timing (not too aggressive, not too passive)

   • Too aggressive: Segfaults from accessing freed memory.
   • Too passive: Hash never gets freed.
   • Just right: Hash freed, time passes, String allocated in same spot.

3. Multi-threaded execution creating memory churn:

   • Increases chances of timing alignment.
   • Multiple allocation/deallocation cycles.

4. The exact microsecond window where:

   • Struct class becomes unreachable.
   • GC runs and collects rbFieldMap.
   • Ruby allocates a String in that exact memory slot.
   • Code tries to access a struct field.

In typical production Karafka processing:

• You define 10-20 struct classes at startup.
• They live for the entire process lifetime.
• Natural GC cycles with moderate pressure.
• The window is measured in microseconds across billions of operations.

~1 in 1,000,000 process restarts

But in high-churn environments:

• Kubernetes pods restarting frequently.
• Serverless functions with thousands of cold starts daily.
• The rare becomes inevitable.

That's how a million-to-one bug causes 2,700 errors in production. Not because it's common, but because when timing finally aligns, it stays aligned. The corrupted state persists until a restart, causing every subsequent operation to fail.

Lessons From the Hunt

After spending days debugging what seemed impossible, here's what stayed with me:

• Sometimes the obvious answer is wrong. I spent a lot of time convinced this was a musl issue. Every diagnostic came back green. Sizes matched. Offsets matched. Alignment matched. Everything. Matched. But the bug wasn't in the data layout - it was in object identity.

• The timing of GC matters as much as whether GC happens. GC.stress finds immediate use-after-free (segfaults). Natural GC timing finds delayed reuse (object transformations). They're different symptoms of the same root cause, requiring different reproduction strategies.

• Million-to-one bugs are real, not theoretical. They happen during initialization and restart, not runtime. When they trigger, they cascade - 2,500 errors from one root cause. In high-restart environments, rare becomes routine.

• Diagnostic scripts can test the wrong layer. My scripts verified static struct layouts perfectly. But they couldn't detect that FFI's internal Hash could be freed by GC and replaced by a String at runtime. The tests passed because they checked structure, not behavior.

• Patience and persistence matter. Groing from the impossible theory to a reproducible bug took days of work. Building the elegant #1079 reproduction helped me understand the timing requirements. Manual write barrier removal showed me the difference between immediate and delayed failures. Multi-threaded stress tests with process farms compressed million-to-one odds into minutes.

Initially, I blamed myself. I guess, that's what maintainership feels like sometimes. You own the stack, even when the bug is deeper than your code.

The fix was already in FFI 1.17.0 when this incident happened. The user just hadn't upgraded yet. Sometimes the "impossible" error you're debugging has already been solved. You just don't know it yet.

Acknowledgments

The root cause - missing write barriers in FFI < 1.17.0 - was fixed in FFI issue #1079 by KJ, who has been my invaluable rubber duck throughout this debugging journey.

The Bottom Line

If you're running FFI < 1.17.0 in production - especially in high-restart environments like Kubernetes, ECS, or serverless platforms - upgrade today. The bug may be one in a million restarts, but at scale, million-to-one odds aren't odds at all.

They're inevitabilities waiting to happen.

And somewhere, right now, a developer is staring at an error log showing many identical crashes, running every diagnostic script they have, seeing all green checkmarks, and thinking: "That's impossible. Everything matches."

But it's not impossible.

It's just waiting for the right microsecond.
